Illumination

White light  LED

Focus

Red light  LED

Supported barcode

2D

QR Code, Data Matrix, PDF417,Aztec, Maxicode，HANXIN CODE

1D

EAN,UPC,Code 39,Code 93,Code 128,UCC/EAN 128, Codabar，

Interleaved 2 of 5, ITF-6,ITF-14,ISBN,ISSN, MSI-Plessey

GS1 Databar,GS1 Composite Code,Code 11,Industrial 25,

Standard 25,Plessey, Matrix 2 of 5

Reading accuracy

≥5mil

Reading depth of field　

EAN-13

50mm-200mm (13mil)

Depth of field can be adjusted according to customer application

Code39

40mm-90mm （5mil 10 byte ）

QR Code

25mm-240mm (20mil 16 byte )

Data Matrix

50mm-90mm （10mil 20 byte ）

PDF 417

30mm-130mm (6.67mil 7 byte )

Contract

≥25%

Scanning angle　

Rotation 360°，Tilt ± 55°，Pitch ± 55°

Field of view

V1

Horizontal 34°，Vertical 28°

V2

Horizontal 42°，Vertical 32°

Communication Interface

 USB (HID-KBW、Virtual serial port),Serial port

Size

43(W)×37.9(D)×21(H)mm

Working Voltage

DC 5V

Working Current

170mA

Standby current

USB

25mA

Serial port

400uA

Operating temperature

 -20℃~+50℃

Storage temperature

 -40℃~+70℃

Relative Humidity

5%~95%（Non-condensing）

Environmental illumination

0~100000LUX
