Feature
USB 2.0 Full Speed Interface CCID Compliance
Smart Card Reader: Read/write speed up to 424 kbps
Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type)
Supports ISO 14443 Type A and B cards, MIFARE, FeliCa, and all 4 types of NFC (ISO/IEC 18092) tags
Built-in anti-collision feature (only 1 tag is accessed at any time)
Application Programming Interface:
Supports PC/SC
Supports CT-API (through wrapper on top of PC/SC)
Peripherals:
User-controllable bi-color LED
User-controllable buzzer
Supports Android™ OS 3.1 and above
Specification
Size | 98.0 mm (L) x 65.0 mm (W) x 12.8 mm (H) |
Weight (g) | 70 g |
Protocol | USB CCID |
Power Source | From USB port |
Speed | USB Full Speed (12 Mbps) |
Cable Length | 1.0 m, Fixed |
Standard | ISO/IEC 18092 NFC, ISO 14443 Type A & B, MIFARE®, FeliCa |
Protocol |
ISO 14443-4 Compliant Card, T=CL |
LED | 1 bi-color: Red and Green |
Buzzer | Monotone |
Certifications/Compliance | EN 60950/IEC 60950, ISO 18092, ISO 14443, USB Full Speed, PC/SC, CCID, VCCI (Japan), KC (Korea), Microsoft® WHQL, CE, FCC, RoHS 2, REACH |
Operating System | Windows® CE, Windows®, Linux®, MAC OS®, Solaris, Android™ |
